© 2011 Thorlabs
45Operating the Beam Profiler
3.3.2.5.4 Plot Orientation
Menu bar: Windows -> Plot Orientation
This windows plots the orientation (in degrees) of the ellipse, see Calculation
Results .
Toolbar
Icon
Associated Action
Opens a dialog box to specify the properties of the saved screenshots /
diagrams.
Toggle button to display grid in the diagram.
Auto scale
Show or hide the cursor
39
