© 2011 Thorlabs
90 Thorlabs Beam 4.0
asymmetry, divergence asymmetry and astigmatism.
Extension set contains
Translation Stage of selectable length incl. controller
Power Supply
RS232 Cable
USB to RS232 converter
2 Mounting Base Plates
Adapter Plate to Beam Profiler
Latest Beam Profiler Software CD
Manual
Note
The BC100 Series Beam Profiler as well as beam focusing and alignment means
are not included in the BC1M2 Extension Set and are sold separately. See
Mechanical Setup for optional equipment.
3.5.4.2
Recommended Accessories
The mentioned in previous section components are mandatory for a M
2
measurement.
Additional accessories are recommended to adapt the M² measurement system to
the laser beam height and it's axis. The following example gives you an idea how to
realize a well-proven and easy-to-build construction for adjusting the beam height
and the beam pointing.
All required components can be purchased at Thorlabs.com. The following tables
93
