Tomey UD-8000 User Manual

3-123 ■
b) Setting gate cursor
■ Settings made here are only effective for the eye
currently selected. Settings cannot be made for both
eyes simultaneously. Complete necessary settings for
each eye.
1) Select a gate cursor to be adjusted by touching the “gate selection” buttons
(1). The selected and active cursor is displayed in red but the other cursors
are displayed in white.
2) Touch the gate cursor movement buttons (2) to set the gate cursor position.
Gate cursor for retina
Gate cursor for cornea
Gate cursor for the front of lens
Gate cursor for the back of lens
3-88
(1)
(Fig. 1)
(2)
