8.2.2 Ultrasound energy
Acoustic Output Reporting Table (FDA)
Application(s): B-Scan
Acoustic Output
15MHz B Probe
MI
Ispta.3
(mW/cm2)
Isppa.3
(W/cm2)
Pre-Amendment Maximum
Acoustic Output
0.23 17 28
Global Maximum Value 0.229 0.600 20.09
pr.3(Mpa) 0.875
W0(mW) 0.00248 0.00248
fc(MHz) 15.0 15.0 15.0
Zsp(cm) 2.00 2.00 2.00
x-6(cm) 0.09 0.09 Beam
dimensions
y-6(cm)
0.09 0.09
PD(usec) 0.143 0.159
PRF(Hz) 3013 3013
Az.(cm) 1.9
Associated
Acoustic
Parameter
EBD
Ele.(cm)
0.9
Acoustic Output
60MHz UBM Probe
MI
Ispta.3
(mW/cm2)
Isppa.3
(W/cm2)
Pre-Amendment Maximum
Acoustic Output
0.23 17 28
Global Maximum Value 0.090 0.060 27.55
pr.3(Mpa) 0.533
W0(mW) 1.811×10
-6
1.811×10
-6
fc(MHz) 60.0 60.0 60.0
Zsp(cm) 0.81 0.81 0.81
x-6(cm) 0.009 0.009 Beam
dimensions
y-6(cm) 0.011 0.011
PD(usec) 0.025 0.026
PRF(Hz) 4500 4500
Az.(cm) 2.06
Associated
Acoustic
Parameter
EBD
Ele.(cm)
0.5
