Tomey UD-8000 User Manual

2-27 ■
2.3.8 A-scan diagnosis (only when AL-4000 is connected)
a) Freeze screen
(1) Video display tab
Displays an image to be displayed on monitor.
(2) Gain indicator
Displays the gain value.
(3) Analysis tool
Displays the tool to be used for the line analysis and the point analysis.
(4) “Reset” button
Touching this button for some length of time deletes the Ref. data and displays the capturing
screen.
