Tomey UD-8000 User Manual

3-39 ■
3.3.2 Displaying probe angle
This function shows the angle in which the B-mode probe is set to diagnose
the patient’s eye.
■ Confirm that the displayed probe angle matches the
probe angle captured in the picture.
1) Touch the “Select Probe Angle” button (1) to open the probe angle
selection window.
(1)
(Fig. 1)
3-33
(2)
(3)
(4)
(Fig. 2)
3-36
