Tomey UD-8000 User Manual

3-177 ■
3.9.6 Analysis function
a) Line analysis
1) Set the line (1) position in real time mode using the line position button (2).
2) Touch the “HRZN” button (3) to return the line to the initial position.
3) Adjust the gain to align the peak of the reference section (Ref. peak) with
the line height.
(3)
(Fig. 1)
(1)
(2)
3-599
(5)
(Fig. 2)
(6)
(4)
(7)
(8)
3-600
