3-172
a) Gain setting
■
Settings made here are only effective for the eye
currently selected. Settings cannot be made for both
eyes simultaneously. Complete necessary settings for
each eye.
Adjust the waveform height according to the gain settings. The gain and the
waveform height increases as the gain value increases.
The gain value (1) displayed in the upper left of the measurement screen
(Fig. 1) can be specified by the rotary encoder (Fig. 2) at the front of the
monitor. The valid value range is 1 to 80 dB.
(Fig. 2)
3-43
3-593
(Fig. 1)
(1)
To Next Page
