2-4
(1) Probe holder
Houses an axial length probe, corneal thickness probe, and B-probe.
(2) Low frequency probe connector
Connects a low frequency probe (15MHz B-probe).
(3) High frequency probe connector
Connects a high frequency probe (60MHz UBM probe).
(4) Extension terminal (UH01, UH02)
Is a connector for extensions.
(5) Video-out terminal (HDMI)
Connects an external monitor.
(6) Maintenance switch
Our service personnel use this switch for maintenance.
(7) Footswitch connector
Connects a footswitch.
(8) USB-D connector
Connects an external printer and personal computer.
(9) USB-H connector
Connects
AL-4000 axial length and corneal thickness measurement instrument, OA-1000
Light Interference Method Axial Length Measurement Instrument, external storage media such
as USB flash memory, a video printer, and an external ID input device, etc.
(10) LAN connector
Connects a LAN cable.
(11) Inlet
Connects a power cord.
(12) Fuse holder
Accepts a fuse.
