Receiver Specifications
P/N 7010-0935
A-3
Receiver Specifications
The following sections provide specifications for the receiver and its
internal components.
General Details
Table A-1 table lists the receiver’s general specifications.
Table A-1. Receiver General Specifications
Physical
Enclosure Aluminum, IP67 rated extrusion
Color Topcon Yellow and Topcon Grey
Dimensions W:166 mm x H:93 mm x D:275 mm
6.54" x 3.66" x 10.83"
Weight 3.0 kg (6.61 lbs)
Antenna External
Controller External MINTER
Keys Two keys:
Power – On/Off
FN – start/stop data logging; switch information mode
LEDs Six LEDs:
STAT – satellite and receiver status
REC – record and data status
RX TX – modem status
LINK – network connection status (currently n/a)
PWR x 2 – power status
Environment
Operating
temperature
-40 C° to +65 C°
Storage temperature -40 C° to +75 C°
Humidity 100% non-condensing
IP rating IP67 waterproof/dustproof
