Net-G3A Configuration and Setup
NET-G3A Operator’s Manual
3-22
Before logging data, make sure the receiver contains current almanac
and current ephemeris data (see “Collecting Almanacs and
Ephemerides” on page 2-14).
Step 1: Set up the Receiver
1. Place the receiver in the predetermined location. A sturdy shelf or
out-of-the-way table may be a convenient spot.
2. For a permanent mount, drill four screws through the mounting
location (shelf) and into the receiver’s mounting holes.
3. Connect the power cable to an available and grounded outlet. See
“Powering the Receiver” on page 2-11 for more details and
precautions.
4. Connect the antenna cable. If recording data to an external device,
such as a USB hard drive, connect it to the receiver using the
required communication cable.
See “Net-G3A Dimensions” on page A-2 for
measurement details regarding the placement of
screw holes for a permanent mount.
Net-G3A_OM_Book.book Page 22 Thursday, May 14, 2009 8:49 AM
