Pre-setup Preparation
NET-G3A Operator’s Manual
2-22
PC-CDU Connection Parameters
When connecting to the receiver via PC-CDU, the type of connection
determines the parameters to select. Table 2-1 and Table 2-2 list the
parameters for the four connection types.
Figure 2-10. PC-CDU Connection Settings – RS232 and USB
Table 2-1. PC-CDU Connection Parameters for RS232 and USB
Parameter RS232 USB
Connection
Mode
Direct
Port Port connecting the computer
and receiver (typically COM1,
COM2 for RS232)
USB
Baud Rate Communication rate between
the receiver and the computer
(usually 115200)
n/a
Rec ID n/a Receiver’s identification
number
Net-G3A_OM_Book.book Page 22 Thursday, May 14, 2009 8:49 AM
