Topcon Net-G3A User Manual

Setting Raw Data & Position Update Rates to 50 Hz
P/N 7010-0935
4-13
Ok – closes the dialog box.
Setting Raw Data & Position
Update Rates to 50 Hz
This procedure sets the receiver to output measurement data and
position information at 50 Hz.
1. In PC-CDU, click ToolsReceiver options.
2. Make sure that the Position update rate (Hz) and Raw data
update rate (Hz) options display 50 in the Current column, and
then click Exit.
3. Click ConfigurationReceiver.
4. Click the Advanced tab, and then the Raw Data Management
tab. Set the following parameters, and then click Apply:
• Raw Measurement Update Rate, Update Rate – set to 20 ms.
• Position Update Rage, Update Rate – set to 20 ms.
5. Click Refresh, and examine the values in the Current Update
Rate fields. They should display 20.
6. Once verified, click OK.
When requesting any data recording or output with a period—that is,
a recording or output not directly supported by the current state of the
receiver—PC-CDU will launch the Output Period Setup Wizard. This
wizard performs the same steps described above. For details on the
wizard, see PC-CDU Reference Manual.
CAUTION
Always initialize the file system on the installed CF
card before the first use. It is recommended to
reinitialize the receiver file system on a regular
basis.
