Introduction
NET-G3A Operator’s Manual
1-18
Mounting Holes
The receiver has four mounting holes on the bottom to install #8-32
screws for a permanent mount (Figure 1-7). Installing the receiver
using these screws prevents unwanted movement.
Figure 1-7. Net-G3A Bottom Mounting Holes
Cables and Power Supply
The Net-G3A package includes standard communication and power
cables for configuring the receiver and providing a power source to
the receiver. Table 1-2 lists these cables.
Table 1-2. Net-G3A Package Cables
Cable Description Cable Illustration
USB Cable
Connects the receiver to an external
device (controller or computer) for
high-speed data transfer and receiver
configuration.
p/n 14-008081-01
This can also be purchased at any
local computer store.
A
Net-G3A_OM_Book.book Page 18 Thursday, May 14, 2009 8:49 AM
