Getting Ready to Pave
Topcon Paver System Five Operator’s Manual
5-2
Control Box Setup
Use the following steps to install the Control Box (Figure 5-5).
1. Attach the Control Box to its bracket.
2. Connect the cables to the Control Box.
3. Turn on the Control Box.
Figure 5-1. Attach Control Box and Connect Cables
NOTICE
NOTICE
Due to different types of machine configuration,
cable connections may vary.
AU
TO
S
UR
VEY
SET
(ME
NU
)
S
ystem
F
ive
P ave r
M ac hin e
C a bl e
S oni c
T r acke
r
C a bl e
S lop e
C a bl e
