Topcon Paver System 5 User Manual

Control Methods
P/N 7010-0341 www.topconpositioning.com
2-23
In the upper right hand corner of the Sonic Tracker II
faceplate is a small symbol used to represent the use of the
temperature bail. The LED symbol automatically
illuminate when the bail is connected to the tracker. The
tracker is cast with holes on each side for the bail to snap
and lock into place (Figure 2-25).
Figure 2-25. Sonic Tracker and Components
S
onic
T
racker
II
S onic T racker II
T
T
