2. Set the Grade Checking Lath on the edge of the newly cut
ground so the level bubble extends over the Sonic Stringline
(Figure 3-17).
Figure 3-17. Check Finished Grade
3. Tilt the Grade Checking Lath to center the level bubble.
Finished grade is correct if the level just touches the Sonic
Stringline (Figure 3-17).
ST R I N GLI N E
FI
N IS H E D G RAD E
A PP R OX. . 05 ' TOO H IG H
ST R I N GLI N E
FI
N IS H E D G RAD E ( C O RR E C T )
