Greensmaster 3250--D Hydraulic SystemPage 4 -- 7 1
Front Wheel Motor Removal (Fig. 47)
1. Park the machine on a level surface, lower the cut-
ting units and stop the engine. Remove key from the
ignition switch.
2. Remove front wheel, brake drum assembly and
brake assembly from machine (see Front Wheel and
Brake in the Service and Repairs section of Chapter 6
-- Chassis).
CAUTION
Before continuing further, read and become fa-
miliar with General Precautions for Removing
and Installing Hydraulic System Components.
3. Label all wheel motor hydraulic connections for as-
sembly purposes.
4. Disconnect both hose assemblies and O--rings from
the hydraulic fittings on the wheel motor. Allow hoses to
drain into a suitable container. Discard removed O--
rings.
5. Mark wheel motor fitting orientation to allow correct
assembly. Remove hydraulic fittings and O--rings from
motor. Discard removed O--rings.
6. Put caps or plugs on disconnected hoses and motor
port openings to prevent contamination.
7. Remove four (4) cap screws (item 4) that secure
brake bracket and hydraulic wheel motor to machine.
Remove brake bracket and motor from the frame.
Front Wheel Motor Installation (Fig. 47)
1. Position hydraulic wheel motor and brake bracket
(item14)totheframe.M akesureportsofmotorfacethe
rear of the machine. Secure motor and brake bracket to
the frame with four (4) cap screws (item 4).
2. Remove plugs from wheel motor ports. Lubricate
and place new O--rings onto fittings. Install fittings into
motor openings making sure that fitting orientation is as
notedduringremoval.Tightenfittings(seeHydraulicFit-
tingIns tallationintheGeneralInformationsectionofthis
chapter).
3. Remove caps from disconnected hydraulic lines.
4. Lubricate and position new O--rings to fittings on
wheel motor. Use labels placed during the removal pro-
cesstoproperlyinstallhydrauliclinestowheel motor fit-
tings (see Hydraulic Hose andTubeInstallationinthe
General Information section of this chapter).
5. Install brake assembly, brake drum assembly and
front wheel to machine (see Front Wheel and Brake in
the Service and Repairs section of Chapter 6 -- Chas-
sis).
Failure t o maintain proper wheel lug nut and
wheel hub lock nut torque could result in failure
orlossof wheeland mayresultin personalinjury.
WARNING
6. Make sure to properly torque lock nut from 250 to
400 ft--lb (339 to 540 N--m) and wheel lug nuts from 70
to 90 ft--lb (95 to 122 N--m).
7. Check oil level in hydraulicreservoirandaddcorrect
oil if necessary.
8. Follow Hydraulic System Start--u p procedures (see
Hydraulic System Start--up in this section).
