Greensmaster 3250--D
Page 5 -- 34
Electrical System
Service and Repairs
NOTE: See the Kubota Workshop Manual for engine
component repair information.
Verify Interlock System Operation
CAUTION
The interlock switches are for the operator’s
protection; do not disconnect them. Check the
operation of the interlock switches daily for
proper operation. Replace any malfunctioning
switches before operating the machine.
The purposes of the interlock switches are to:
A. Prevent the engine from cranking or starting un-
less the functional control lever is in NEUTRAL.
B. Prevent operating the traction pedal with the
functional control lever in NEUTRAL.
C. Shutoffthe engineifthe operatorleavestheseat
without the functional control lever in NEUTRAL.
D. Shut off the reels if the functional control lever is
moved to NEUTRAL or TRANSPORT.
1. Sit on the seat, engage parking brake and move
functional control lever to NEUTRAL. Try to depress
traction pedal. If the pedal does not depress, the inter-
locksystemisoperatingcorrectly.Correctproblemifnot
operating properly.
2. Sit on the seat, engage parking brake, keep traction
pedal in neutral and place functional control lever in
MOWorTRANSPORT.Trytostartthe engine.Ifthe en-
gine does not crank, the interlock system is operating
correctly. Correct problem if not operating properly.
3. Sitontheseatandstartengine.Movefunctionalcon-
trollevertoMOW.R aiseofftheseat.Iftheenginestops,
theinterlocksystemisoperatingcorrectly.Correctprob-
lem if not operating properly.
4. Sit on the seat, engage parking brake, keep traction
pedal in neutral and place functional control lever in
NEUTRAL. Start the engine. Move joystick forward to
lower the cutting units. If the units do not start r otating,
theinterlocksystemisoperatingcorrectly.Correctprob-
lem if not operating properly.
