Greensmaster 3250--DHydraulic System Page 4 -- 48
Steering Valve Test
1160 PSI
Steering Cylinder
PET
LR
STEERING
VALVE
4.5
TO CONTROL
MANIFOLD
PORT P2
TO CONTROL
MANIFOLD
PORT ST
FROM GEAR
PUMP
PLUG
TURNED FOR
RIGHT TURN
(CYLINDER ROD
FULLY RETRACTED)
