Chapter 4 Recording and Storage
To configure these settings, right click on the Live View screen and click Settings in the pop-up main
menu. Then go to Storage > Recording Controls and select Storage Disk Group. Click Save after you
finish the configuration.
Channel Displays the name of camera in this channel.
Recording Switch Start/stop recording on the selected channel.
Storage Stream
Select the stream for recording.
Main (Main Stream): The size of recording files will be larger when
selected.
Substream: The size of recording files will be smaller when selected.
Storage Disk Group Select the disk group for the NVR with multiple hard drives.
4. 2. 2 Configure Disk Quota
In Disk Quota, you can manually start and stop recording on certain channels, select the stream for the
storage of recordings, check the used capacity of hard drive on certain channels, and assign the disk
quota to cameras to store recordings.
