Tracker 600 - Assembly Schematic

57
Assembly Schematic
ATV597cc_22_1
18 N-m
13 ft-lb
8 N-m
70 in.-lb
Loctite +
Steps
1. 10 N-m
88 in.-lb
2. 30 N-m
22 ft-lb
3. 90° turn
4. 90° turn
18 N-m
13 ft-lb
21.5 N-m
16 ft-lb
9 N-m
80 in.-lb
Sealant +
15 N-m
11 ft-lb
3.75 N-m
33 in.-lb
67.5 N-m
50 ft-lb
18.5 N-m
14 ft-lb
13.5 N-m
10 ft-lb
9 N-m
10 in.-lb
Loctite +
5 N-m
45 in.-lb
Loctite +
5 N-m
45 in.-lb
10 N-m
88 in.-lb
10 N-m
88 in.-lb
10 N-m
88 in.-lb
24 N-m
17.7 ft-lb
Oil bolt head
and thread;
Steps
Crisscross
1. 10 N-m
88 in.-lb
2. 30 N-m
22 ft-lb
3. Another 70° turn
10 N-m
88 in.-lb
10 N-m
88 in.-lb
15 N-m
11 ft-lb
22 N-m
16 ft-lb
10 N-m
88 in.-lb
Steps
Crisscross
Tighten
Crisscross
9 N-m
80 in.-lb
