90
NOTE: If the throttle body, ECM, TPS, or ISC are
replaced, the EFI system must be synchronized. Use
the following procedure:
1. With the key off, depress throttle lever to Wide Open
Throttle (WOT).
2. Place the ignition key in the ON position and wait for
10 seconds.
3. Release the throttle lever, and wait an additional 10
seconds.
4. Turn the key to the OFF position and allow the gauge
to shut off.
RPM Limiter
NOTE: The ATV is equipped with an ECM that cuts fuel spray and spark when maximum RPM is
approached. When the RPM limiter is activated, it could be misinterpreted as a high-speed misfire.
Component data can be retrieved using the Dealer Diagnostic System. Utilize the Sensor Data screen.
Gear Park Neutral Reverse High/Low Fail-Safe Mode
Incorrect
ECU/Gauge
(P0630)
Warranty
Registration
(U1001)
2WD
2250 6500 4000
7250 4000 6650 4500
4WD
4WD Lock
2WD Override 2250 6500 5000
4WD Override
2250 6500 7000
Differential-Lock Override
