Chapter 6 UCMs supported by Tracer Summit systems
68 BMTX-SVN01C-EN
71 on on on OFF OFF OFF on OFF
72 OFF OFF OFF on OFF OFF on OFF
73 on OFF OFF on OFF OFF on OFF
74 OFF on OFF on OFF OFF on OFF
75 on on OFF on OFF OFF on OFF
76 OFF OFF on on OFF OFF on OFF
77 on OFF on on OFF OFF on OFF
78 OFF on on on OFF OFF on OFF
79 on on on on OFF OFF on OFF
80 OFF OFF OFF OFF on OFF on OFF
81 on OFF OFF OFF on OFF on OFF
Table 14. LCP supervisor DIP switch settings (Continued)
UCM
address
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8
Table 15. LCP address (options select) DIP switch settings
UCM
address
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8
82 OFF on OFF OFF on OFF on OFF
83 on on OFF OFF on OFF on OFF
84 OFF OFF on OFF on OFF on OFF
85 on OFF on OFF on OFF on OFF
86OFFon onOFFonOFFonOFF
87 on on on OFF on OFF on OFF
88 OFF OFF OFF on on OFF on OFF
89 on OFF OFF on on OFF on OFF
90OFFonOFFon onOFFonOFF
91 on on OFF on on OFF on OFF
92 OFF OFF on on on OFF on OFF
93 on OFF on on on OFF on OFF
94OFFononononOFFonOFF
95 on on on on on OFF on OFF
96 OFF OFF OFF OFF OFF on on OFF
97 on OFF OFF OFF OFF on on OFF
98 OFF on OFF OFF OFF on on OFF
99 on on OFF OFF OFF on on OFF
100 OFF OFF on OFF OFF on on OFF
101 on OFF on OFF OFF on on OFF
