Trane Tracer Summit Hardware And Software Installation

Chapter 6 UCMs supported by Tracer Summit systems
74 BMTX-SVN01C-EN
Table 18. TCM address settings
TCM DIP switch settings
UCM address S1-1 S1-2 S1-3 S1-4 S1-5 S1-6
1 OFF on on on on on
2 on OFF on on on on
3 OFFOFFonononon
4 on on OFF on on on
5 OFFonOFFononon
6 onOFFOFFononon
7 OFF OFF OFF on on on
8 on on on OFF on on
9 OFF on on OFF on on
10 on OFF on OFF on on
11 OFF OFF on OFF on on
12 on on OFF OFF on on
13 OFF on OFF OFF on on
14 on OFF OFF OFF on on
15 OFF OFF OFF OFF on on
16 on on on on OFF on
17 OFF on on on OFF on
18 on OFF on on OFF on
19 OFF OFF on on OFF on
Table 19. TCM configuration DIP switch settings
Programming options
TCM DIP switch settings
S1-7 S1-8
Slave OFF OFF
Air conditioning thermostat OFF on
Heat pump thermostat on OFF
Test mode on on
