Operating instructions: Outfeed conveyor TS 4800
Version 3.6ENG, 27.01.2020
Numbers of rollers each swivel
roller assembly
6 to 14
Roller diameter (DR) Ø50 mm
Offset (transaxles) 60 120 mm
Transfer angle (wN) 30° 45° 90°
Transfer direction (rF) right left double-sided (90° only)
Track load (QF) max. 50 kg/m
conveying speed (vF) max. 2 m/s
Drive power (PN) 0.37 - 1.5 kW, depending on load and speed, see
contract specifications or motor identification tag
Type of drive Gear motor
Electrical data
Designation Data
Motor voltage supply – drive Standard: 230 V / 400 V AC 50 Hz,
for deviations, see motor type identification plate
Motor brake voltage – drive Standard: 230 V AC / 400 V AC, see motor type
identification plate for variations
Protection class Standard: IP55, not protected against explosion
Pneumatic specifications, pneumatic swivel roller bar
Designation Data
Valve supply voltage 24 V DC
Compressed-air supply min.6 bar max. 10 bar filtered air - no lubricated or
permanently lubricated air
Compressed air settings Factory setting approx. 3.5 to 4.0 bar
- dependent on swivel roller bar
- changes to the factory setting increase wear
Cut-out pressure Swivel roller bar operating pressure
Installation location requirements
Designation Data
Ambient temperature 5 °C to +40 °C, temporary up to +50 °C (max. 1 h)
Relative air humidity max. 80 %
Mechanical Data TS 4800 (contd.)
Designation Data
