transnorm TS 4800 - Parts of the Machine

Description
Parts of the machine
32
Operating instructions: Outfeed conveyor TS 4800
Version 3.6ENG, 27.01.2020
Parts of the machine
Parts TS 4800 Outfeed conveyor, example illustration
Picture illustration
No. Designation
1 Side guide (optional)
2 Front cover
3 Support / conveyor leg (optional)
4 Bottom cover
5 Conveyor bed
6 Swivel roller assembly
Picture illustration
No. Designation No. Designation
1 Idler roller 8 Bottom cover
2 Side guide support 9 Swivel roller assembly
3 Drive belt 10 Tail pulley
11
3
1
9
6
4
2
12
7
10
5
8
13
