transnorm TS 4800 - Auxiliary Equipment

Transportation and erection
In-company transportation
38
Operating instructions: Outfeed conveyor TS 4800
Version 3.6ENG, 27.01.2020
Auxiliary equipment
Required auxiliary materials
Overhead crane, gantry crane Safe working load 2,000 kg
Industrial truck Safe working load 2,000 kg
min. lifting height 4,000 mm
Lift truck cross beam,
safe working load 2,000 kg
Lift truck hook,
safe working load 2,000 kg
Adjustable cross beam,
safe working load 2,000 kg
L max. = 4,000 mm
L min. = 2,000 mm
Adjustable cross beam, double
safe working load 2,000 kg
La max. = 4,000 mm
La min. = 2,000 mm
Lb max. = 2,000 mm
Lb min. = 1,000 mm
Round slings,
safe working load 1,000 kg
U min = 3 m
