1 Introduction
Instrument case
The instrument case is made of lightweight HPX resin. This is strong and durable and ensures a
watertight, airtight, dust-proof, chemical resistant and corrosion proof environment for the
scanner.
The case has a Vortex® valve on the front that can be used to equalize the atmospheric pressure
after quick changes. It also has heavy duty wheels with stainless steel bearings, telescoping handle,
and press and pull latches.
The TX8 3D scanner is fitted into a high-density foam mould that protects it against impact,
vibration, and shock.
Left/front side view
Item Description
❶ Press and pull latch
❷
Double-layered, soft grip handle
❸ In-line wheel
❹ Press and pull latch (x 2)
❺ Auto-pressure release valve
❻ Double-layered, soft grip handle
Trimble TX8 3D Laser Scanner User Guide 12
