Trimble TX8 - Scanner only specifications; Shipping box specifications; Instrument case specifications; External power supply specifications

5 Specifications
Scanner only specifications
Dimensions (W x H xD - scanner only) 335 mm x 412 mm x 242 mm
Volume (scanner only) 26921 cm
Weight 11.8 kg (without tribrach, battery, or USB flash drive)
Operation
The Trimble TX8 3D scanner, is classified IP54 according to
the international standard IEC 60529. It is a night and day
scanner that can scan under the following conditions:
l Wet or dry weather (humidity range from 0% to 80%),
l Hot or cold conditions (temperature range from 0 °C to
+40 °C).
Maximum sound level 73 dB
Storage The instrument can be stored inside its box at temperatures
ranging from -20 °C to +50 °C.
Shipping box specifications
Dimensions (W x H xD) 475 mm x 720 mm x 595 mm
Weight 2.5 kg (empty)
Instrument case specifications
Dimensions (L x W x D - scanner only)
Exterior: 625 x 500 x 366 mm
Interior: 559 x 432 x 322 mm
Weight 10.61 kg (with foam), 8.83 kg (without foam)
Temperature range -29 °C to 60 °C
External power supply specifications
Dimensions (W x H x D)
130 mm x 76.2 mm x 43.7 mm
Weight 660 g
Cable length
Power cable connected to unit: 1.8 m
Power cable provided with connectors: 2.1 m
Temperature range -29 °C to 60 °C
Voltage
Input: 90 to 264 V AC
Output: 12 V
Frequency
Input: 47 - 63 Hz
Trimble TX8 3D Laser Scanner User Guide 95
