MAINTENANCE AND ADJUSTMENT
140
All Models
▼ Remove the expansion tank cap.
▼ Add coolant mixture through the
filler opening until the level reaches
the MAX mark.
▼ Fit the expansion tank cap.
1. Expansion tank cap (Trident shown)
2. Expansion tank cover
3. Expansion tank
4. MAX mark
5. MIN mark
Daytona660 Only
▼ Fit the deflector fairing as follows.
▼ Position the deflector fairing locating
feature onto the retaining tang and
press the panel into the retaining
grommet and clip.
1. Retaining grommet
2. Retaining clip
3. Retaining tang
4. Locating feature
NOTICE
If the coolant level is being checked
because the coolant has overheated,
also check the level in the radiator and
top up if necessary.
In an emergency, distilled water can
be added to the cooling system.
However, the coolant must then be
drained and replenished with D2053
OAT coolant as soon as possible.
Coolant Change
We recommend that the coolant is
changed in accordance with scheduled
maintenance requirements.
