MAINTENANCE AND ADJUSTMENT
134
Engine Oil and Oil Filter Change
WARNING
Always wear suitable protective
clothing and avoid skin contact with
used engine oil.
Prolonged or repeated contact with
engine oil can lead to skin dryness,
irritation and dermatitis.
Used engine oil contains harmful
contamination that can lead to skin
cancer.
Failure to follow the advice above
could result in serious injury or death.
CAUTION
The engine oil may be hot.
Avoid contact with the hot engine oil
by wearing suitable protective
clothing, gloves and eye protection.
Contact with the hot engine oil may
cause minor to moderate injury to
exposed skin.
CAUTION
If the engine has recently been
running, the exhaust components may
be hot to the touch.
To avoid skin damage, always allow the
hot parts to cool before touching the
exhaust system.
Contact with the hot components may
cause minor to moderate injury to
exposed skin.
The engine oil and engine oil filter must
be replaced in accordance with
scheduled maintenance requirements.
To change the engine oil and engine oil
filter:
▼ For Daytona 660 remove the left
hand fairing, see page93.
▼ Warm up the engine thoroughly and
stop the engine.
▼ Position the motorcycle on level
ground and in an upright position.
▼ Place an oil drain pan beneath the
engine.
▼ Remove the oil drain plug.
▼ Discard the sealing washer.
▼ Unscrew and remove the oil filter
using Triumph service tool T3880313.
Dispose of the old oil filter in an
environmentally friendly way.
▼ Apply a thin smear of clean engine oil
to the sealing ring of the new oil
filter.
▼ Fit the oil filter and tighten to 10 Nm.
▼ After the oil has completely drained
out, fit a new sealing washer to the
drain plug.
▼ Fit and tighten the drain plug to 25
Nm.
1. Engine oil filter (Trident shown)
2. Engine oil drain plug
