Troxler EGauge Combo 4540 User Manual

4–30
Asphalt Mode
1. Select the Asphalt mode (see page 3-8).
2. If desired, enter, change, or enable the Gmb (Marshall), Gmm value.
3. Select None for Moisture Input.
4. Select count time and background time as described on page 3–10
and 3-11.
5. Prepare the test site and position the gauge as described on page
4–2.
6. With the source rod in the SAFE position, press START.
7. After initialization, follow the instructions on the display.
8. The gauge leads you through the procedure described in the
section Taking Density Measurement on page 4-15.
4-16
WD= xxx.x
M= xxx.x %M=xxx.x
↨
%Gmb= xxx.x
↨
DC= xxx
BC= xxxx
↨
Lat: + x x x.x
Lng: + x x x.x
