3-4-3
Orig
CD373
Chapter 3
MZ Tow Tractor Section 4
5. Repeat steps (3) and (4) for the front brake outlet port with the rear brake outlet plugged.
6. Tighten the plugs and attempt to depress the piston. The piston will resist depression after all
air is expelled.
7. Install the cover and diaphragm assembly, being sure the cover retainer is tightened securely.
Remove the plugs.
F. MASTER CYLINDER INSTALLATION
1. Open console door.
2. Slide master cylinder onto push rod.
3. Mount cylinder body using two (2) mounting bolts and nuts.
4. Unplug cylinder brake line ports.
5. Attach brake lines to brake line ports.
6. Bleed all brake lines using procedure given in Chapter 3, Section 5, paragraph E.
