2-3-4
Orig
CD373
Chapter 2
Section 3 MZ Tow Tractor
(3) Plug brake line ports or drain brake fluid into appropriate container.
(4) Remove two (2) mounting bolts and nuts.
(5) Slide master cylinder off of push rod.
(b) Installation:
(1) Open console door.
(2) Slide master cylinder onto push rod.
(3) Mount cylinder body using two (2) mounting bolts and nuts.
(4) Unplug cylinder brake line ports.
(5) Attach brake lines to brake line ports.
(6) Bleed all brake lines. See Chapter 3, Section 5, paragraph E.
5. Steering Wheel
(a) Removal:
(1) Remove horn button from center of steering wheel.
(2) Disconnect horn button wires.
(3) Remove nut from center of steering wheel.
(4) Use steer wheel puller to remove the steering wheel.
(b) Installation of the steering wheel is performed by reversing the order of steps
5.(a)(1-4).
6. Steer Valve
(a) Removal:
(1) Remove steering wheel (see Part B.5. of this section).
(2) Disconnect horn wires.
