Curtis 1311 Manual
1.2 Model Variants
Model 1311 Handheld Programmer is offered in four access
level models:
• 1311-1101 User programmer
(most restrictive programmer; limited view into the system
and a limited number of parameters and operations)
• 1311-2201 Service programmer
• 1311-3301 Dealer programmer
• 1311-4401 OEM programmer
(the broadest access to parameters and system values).
In order to connect the 1311 Programmer to a Curtis product,
one of three cables must be attached:
• Conxall for the 1288 and MC-2 product line
• RJ11 for the 1207 motor controller
• Molex for all other Curtis products, including 1207A
Each cable must be ordered separately.
1.3 Specifications
Operating Ambient Temperature -10°C to 50°C
Storage Temperature - 40°C to 70°C
Environmental Protection IP20
Weight 0.4 Kg
Plug the 1311 into a Curtis programmer port only. Voltages
and other interface circuits can result in permanent damage
to the programmer !
