Chapter 1
MZ Tow Tractor Section 2
2. Master (“Ignition”) Switch
The ignition switch is the main power switch for all systems. When the switch is ON, power
is made available for the throttle, hydraulics, and all related systems. When the switch is OFF,
power is not available for any systems, including lights and horn.
3. Headlight Switch
The headlight switch is a standard on-off toggle switch, providing power to the headlights. The
headlights will not work if the Master switch is in the OFF position.
Figure 2-2. Multifunction Display
