2-3-5
Orig
CD373
Chapter 2
MZ Tow Tractor Section 3
(3) Remove (4) mounting bolts.
(4) Slide steer valve assembly down through hole.
(5) Remove hydraulic lines.
(b) Installation:
(1) Attach hydraulic lines to steer valve (see Steering Column Assembly in
Chapter 4, Section 2).
(2) Align steer valve with column so that line ports face toward front of vehicle.
Wire attachment points should be on driver's right side of column.
(3) Slide steer valve assembly up through mounting hole. Hold assembly
together as bolts are worked through holes and column flange, and into steer
valve.
(4) Tighten four (4) mounting bolts.
(5) Connect horn wires.
(6) Attach steering wheel (see Part B.5. of this section).
(7) Check fluid level in hydraulic pump reservoir.
7. Tires and Wheels
(a) Rear Tire and Wheel Removal:
(1) Jack rear wheels off the ground using normal jacking procedures found in
Chapter 2, Section 1, paragraph G.
(2) Remove the ten (10) lug nuts which secure the wheel to the drive axle hub
and remove the wheel.
(3) Remove the tire for repair or replacement as required, using proper tire tools.
(b) Rear Tire and Wheel Installation:
(1) Install the new or repaired tire onto the wheel.
(2) Install the wheel to the hub with ten (10) lug nuts and torque to 90 ft-lb.
