Chapter 4
MZ Tow Tractor Section 1
2. Part Number
Parts are identified by part numbers assigned by TUG or, in the case of fasteners and related
materials, by industry standard specification. In a few instances, TUG part numbers are not
available. See the following illustration for further explanation of Part Numbers.
Fig &
Ind
Tug Part
Number
Description
46-1 TM1-1-9693 Engine, Deutz F4M2011 Tier II
ENG-M1A-24 Engine, Deutz FM2011, without
46-2 TM1-ND-5046 Adapter (Oil Sensor Metric to E
46-3 TM1-ND-5047 Reducer, Oil Sensor (Deutz)
46-4 T6-1001-133 Sender, Oil Pressure (Bore & Ta
46-5 MD-P21-105 Isolator, Trasmission, Mount C6
46-6 T6-1008-111 Transmission, C6, 3 Speed
46- T6-1001-101TP Parts, Transmission
46-7 02-02-140239 Fitting, 90°
46-8 ------ Pump, Oil (Included with Engine
46-9 TM1-2-9739 Bracket, Exhaust at Engine
46-10 999-0230A Adapter, Drive
46-11 TPG-D5TZ-6375A Flywheel Assembly, C6
46-12 660-2-2320 Closeout, Flywheel - Diesel (De
46-13 ½-13 x 1 Bolt, Hex Head Ø ½-13 x 1" Lon
46-14 T6-7016-105 Cable, Ground, Braided 12EE
46-15 ------ Arm, Shift (Part of Transmission
46-16 ------ Dipstick Assembly, Transmissio
Part number assigned by
TUG.
No TUG part number indicates that TUG has not assigned a part
number to the part. It may also indicate that the part is not
supplied separately from another part to which it is related.
3. Description and Quantity
A description and quantity is provided for each part listed in the IPL. The quantity given for
subassemblies and subparts is the number of subassemblies/parts contained in the component
or system depicted by the associated illustration, not necessarily the entire vehicle.
