TUG MZ - Page 141

4-2-3
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-1. Body Components
Fig &
Ind
Tug Part
Number
Description Qty Effective
1-1 MZ-10001K Frame Weldment Kit 1 1 & Up
1-2 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long 3 "
1-3 ¼ Washer, Lock ¼" ID 3 "
1-4 ¼ Washer, Flat ¼" ID 3 "
1-5 MZ-10027 Plate, Master Cylinder Cover 1 "
1-6 MX4-10308 Guard, Hip - Passenger Side - Opt. 1 As Req'd
1-7 3/8-16 x 1 Bolt, Hex Head Ø 3/8-16 x 1" Long 2 1 & Up
1-8 3/8 Washer, Lock 3/8" ID 2 "
1-9 3/8 Washer, Flat 3/8" ID 2 "
1-10 MX4-10151 Panel, R/H Control, Closeout 1 "
1-11 5/16-18 x ¾ Screw, Bulk Head Ø 5/16-18 x ¾" Long 8 "
1-12 MX4-10052 Door, Access Console 1 "
1-13 M3-1-8013 Hinge, Console Door 1 "
1-14 5/16-18 x 1 Bolt, Hex Head Ø 5/16-18 x 1" Long 4 "
1-15 5/16 Washer, Flat 5/16" ID 4 "
1-16 5/16-18 x 1 Bolt, Hex Head Ø 5/16-18 x 1" Long 2 "
1-17 5/16 Washer, Flat 5/16" ID 2 "
1-18 MX4-10053 Cover, Console 1 "
1-19 MZ-10019 Panel, Console Access 1 "
1-20 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long 6 "
1-21 ¼ Washer, Lock ¼" ID 6 "
1-22 ¼ Washer, Flat ¼" ID 6 "
1-23 MX4-10054 Rail, Baggage 1 "
1-24 3/8-16 x 1 Bolt, Hex Head Ø 3/8-16 x 1" Long 8 "
1-25 3/8 Washer, Lock 3/8" ID
16
"
