MZ Tow Tractor Section 2
Table 2-1. Body Components (Cont'd)
Fig &
Ind
Tug Part
Number
Description Qty Effective
1-26 3/8 Washer, Flat 3/8" ID 8 1 & Up
1-27 ¼-20 x 1 Bolt, Hex Head Ø ¼-20 x 1¼" Long 4 "
1-28 ¼ Washer, Flat ¼" ID 4 "
1-29 ¼ Washer, Lock ¼" ID 4 "
1-30 MZ-10006 Closeout, Drive Motor 1 "
1-31 MX4-10152 Panel, L/H Control, Closeout 1 "
1-32 MX4-10153 Hinge, Control Closeout 2 "
1-33 MX4-10157 Bolt, Shoulder 4 "
1-34 5/16-18 Nut, Flange Lock Hex 5/16-18 4 "
1-35 MX4-10113 Cover, Conduit Channel 1 "
1-36 MD-CB1-127 Bushing 4 "
1-37 MX4-10180 Gasket, Neoprene - Side Compartment, 6' Long 2 "
1-38 3/8-16 x 1 ¾ Bolt, Hex Head Ø 3/8-16 x 1¾" Long - Opt. 5 As Req'd
1-39 3/8 Washer, Flat, 3/8" ID - Opt. 10 "
1-40 3/8-16 Nut, Top Lock Hex 3/8-16 - Opt. 5 "
1-41 MX4-10202 Bumper, Front Rubber "M" Style - Opt. 1 "
1-42 T-S1 Decal, Maximum Towing Speed 15 MPH 1 Up to 80
617501-03 Decal, Towing Speed 15 MPH 1 81& Up
1-43 TY-57 Decal, Tow with Arrow 3 1 & Up
1-44 MX4-10312 Cover Plate, 1/8"
1
1 & Up
MX4-10192 Connector, Duct Heater, thru Frame - Opt. 1 As Req'd
1-45
440E-98011 Decal, TUG 1 1 & Up
1-46 MJ-ND-4006 Ring, Lashing, 5/8 x 4.25 x 4.25" 3 "
1-47 MX4-10055 Guard, Hip - Right Side 1 "
1-48 T6-9011-149 Plate, Data - Draw Bar 1 "
1-49 M3-1-1048 Decal, Electric
1
"
