TUG MZ - Page 145

4-2-7
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-2. Body Components - Rear
Fig &
Ind
Tug Part
Number
Description Qty Effective
2-1 T6-4044-200 Hitch Assembly, UPS - Opt. 1 As Req'd
T6-9011-535 Hitch, "E", 1.25" Bolt-On with Lip - Opt. 1 "
T6-4025-105 Hitch, Pintle (with Chain) - Opt. 1 "
T6-4025-103 Hitch, Holland 400 CA - Opt. 1 "
2-2 T6-9011-479 Bracket, Bolt-On Hitch Block - Opt. 1 "
MX4-10345 Mount, Front "E" Hitch - Opt. 1 "
MX4-10215 Plate Weldment, Front Pintle - Opt. 1 "
T6-9011-647 Extension, Holland Hitch - Opt. 1 "
2-3 M3-ND-5011 Mirror, 5" Convex - Opt. 2 "
2-4 T6-9011-383 Bracket, Mirror - Opt. 2 "
2-5 T6-9003-303 Bolt, Striker - Opt. 2 "
2-6 MX4-10341 Bracket, Striker Bolt - Opt. 2 "
2-7 T6-4014-103 Hitch Assembly, E-Standard 1 1 & Up
T6-4025-103 Hitch, Holland 400 CA - Opt. 1 As Req'd
T6-4025-108 Hitch, Pintle with Push Button - Opt. 1 "
2-8 T6-4014-123 Bracket, Hitch Extension 1 1 & Up
T6-9011-647 Extension, Holland Hitch - Opt. 1 As Req'd
T6-4014-130 Bracket, Hitch Extension - Opt. 1 "
T6-9011-479 Bracket, Bolt-On Hitch Block - Opt. 1 "
T6-4014-122 Bracket, Hitch, Extension - DAL Opt. 1 "
2-9 MJ-ND-4006 Ring, Lashing, 5/8 x 4.25 x 4.25" 3 1 & Up
2-10 TY-57 Decal, Tow with Arrow 3 "
2-11 660-ND-1438 Box & Cover, Switch, Electric Control - Opt. 1 As Req'd
2-12 MX4-10338 Cover, Rapid Charger 1 1 & Up
2-13 T-S2 Decal, 45 psi 2 "
2-14 M3-1-1048 Decal, Electrical 1 "
2-15 T-S3 Decal, 60 psi 2 "
2-16 T-R6 Decal, 2-Piece Wheel 2 "
2-17
MZ-10001K Frame Weldment Kit 1 "
2-18 T6-200-105 Safety-Walk 12" x 60' (Price/Ft) 7 "
2-19 MZ-10041 Stiffener, MZ Frame - Opt. 2 As Req'd
2-20 MZ-10113 Strip, Rub, Mid Section - Opt. 2 "
2-21 MZ-10114 Rail, Rub, Left Rear - Opt. 1 "
2-22 MZ-10115 Rail, Rub, Right, Rear - Opt. 1 "
2-23 T6-4044-200 Hitch Assembly, UPS - DAL Opt. 1 "
