TUG MZ - Page 149

4-2-11
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-3. Cab Assembly (Optional)
Fig &
Ind
Tug Part
Number
Description Qty Effective
3-1 MZ-10057 Cab Assembly, Weldment - MZ 1 As Req'd
3-2 MZ-10050 Door, White Steel - L/H 1 "
MZ-10036 Door, Beige Vinyl - L/H 1 "
MZ-10034 Door, White Vinyl - L/H 1 "
3-3 T6-9003-153 Strip, Foam, Rear, 8 ft. 1 "
3-4 MZ-10065 Insulation, Rear, Cab 1 "
3-5 MX4-10102 Windshield, Front 1 "
3-6 MG-1-320 Trim-Lock, 12.5' Long 1 "
3-7 MZ-10049 Door, White Steel - R/H 1 "
MZ-10037 Door, Beige Vinyl - R/H 1 "
MZ-10035 Door, White Vinyl - R/H 1 "
3-8 MX4-10100 Glass, Rear Window - Raised Cab 1 "
3-9 MG-1-320 Trim-Lock, 9.5' Long 1 "
3-10 3/8-16 x 3 Bolt, Hex Head Ø 3/8-16 x 3" Long 4 "
3-11 3/8 Washer, Flat 3/8" ID 8 "
3-12 3/8-16 Nut, Top Lock Hex 3/8-16 4 "
3-13 MZ-10052 Panel, Roof 1 "
3-14 MX4-10154 Headliner, Foam 1 "
3-15 MX4-10322
Handles, Grab, Cab 2
"
