TUG MZ - Page 151

4-2-13
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-4. Cab Assembly Components (Optional)
Fig &
Ind
Tug Part
Number
Description Qty Effective
4-1 MZ-10057 Cab Assembly, Weldment 1 As Req'd
4-2 5/16-18 x 1¼ Bolt, Hex Head Ø 5/16-18 x 1¼" Long 4 "
4-3 5/16 Washer, Flat 5/16" ID 4 "
4-4 MX4-10155 Mount, Heater 1 "
4-5 5/16-18 Nut, Top Lock Hex 5/16 -18 4 "
4-6 M3-1-8009 Heater 1 "
4-7 ------ Clamp, Hose IDEAL 5040 2 "
4-8 MX4-10181 Hose, Electric Heater 2 "
4-9 3/8-16 x 1 Screw, Phillips Head Ø 3/8-16 x 1" Long 3 "
4-10 MZ-10033 Light, Dome - LED 1 "
4-11 MZ-10038 Mount, Dome Light 1 "
4-12 T6-7010-114 Switch, Toggle 1 "
4-13 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long 4 "
4-14 ¼ Washer, Lock ¼" ID 4 "
4-15 ¼ Washer, Flat ¼" ID 4 "
4-16 920408C1 Mirror Assembly
1
"
