MZ Tow Tractor Section 2
Table 2-5. Door Assembly - Left Side (Optional)
Fig &
Ind
Tug Part
Number
Description Qty Effective
5-1 MZ-10063 Insulation, L/H Door 1 As Req'd
5-2 CMA-504 Strip, Seal - Door, 16.5' Long 1 "
5-3 MZ-10050 Door, White Steel - L/H 1 "
5-4 MZ-10059 Closeout, L/H Door Panel 1 "
5-5 MZ-10101 Linkage, Door 1 "
5-6 MZ-10100 Adapter, Door Linkage 1 "
5-7 MZ-10069 Latch, Two Rotor L/H 1 "
5-8 ¼-20 x ¾ Bolt, Socket Head Ø ¼-20 x ¾" Long 13 "
5-9 ¼ Washer, Lock ¼" ID 15 "
5-10 ¼ Washer, Flat ¼" ID 15 "
5-11 10-24 x ½ Screw, Slotted Machine Hex Ø 10-24 x ½" Long 4 "
5-12 MZ-10073 Bracket, Handle Mounting 2 "
5-13 MZ-10067 Handle, Non-Locking L/H Paddle 1 "
5-14 CMA-450 Window, L/H Double Slide 1 "
5-15 10-16 x ¾ Screw, Pan Head, Self-Tapping Ø 10-16 x ¾" Long 15 "
5-16 MZ-10062 Handle, Door Pull 1 "
5-17 ¼-20 Nut, Insert ¼-20 9 "
5-18 MZ-10061 Hinge, L/H Door 2 "
5-19 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long
4
"
