TUG MZ - Page 155

4-2-17
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-6. Door Assembly - Right Side (Optional)
Fig &
Ind
Tug Part
Number
Description Qty Effective
6-1 MZ-10064 Insulation, R/H Door 1 As Req'd
6-2 CMA-504 Strip, Seal - Door, 16.5' Long 1 "
6-3 MZ-10049 Door, White Steel - R/H 1 "
6-4 MZ-10058 Closeout, R/H Door Panel 1 "
6-5 MZ-10101 Linkage, Door 1 "
6-6 MZ-10100 Adapter, Door Linkage 1 "
6-7 MZ-10070 Latch, Two Rotor R/H 1 "
6-8 ¼-20 x ¾ Bolt, Socket Head Ø ¼-20 x ¾" Long 13 "
6-9 ¼ Washer, Lock ¼" ID 15 "
6-10 ¼ Washer, Flat ¼" ID 15 "
6-11 10-24 x ½ Screw, Slotted Machine Hex Ø 10-24 x ½" Long 4 "
6-12 MZ-10073 Bracket, Handle Mounting 2 "
6-13 MZ-10066 Handle, Non-Locking R/H Paddle 1 "
6-14 CMA-451 Window, R/H Double Slide 1 "
6-15 10-16 x ¾ Screw, Pan Head, Self-Tapping Ø 10-16 x ¾" Long 15 "
6-16 MZ-10062 Handle, Door Pull 1 "
6-17 ¼-20 Nut, Insert ¼-20 9 "
6-18 MZ-10060 Hinge, R/H Door 2 "
6-19 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long
4
"
