TUG MZ - Page 157

4-2-19
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-7. Instrument Panel Assembly
Fig &
Ind
Tug Part
Number
Description Qty Effective
7-1 T6-1010-159 Decal, "Made in USA" 1 1 & Up
7-2 ML-26 Decal, "Caution" 1 "
7-3 TM1-1-6535 Switch, Dual Wiper - Opt. 1 As Req'd
7-4 M3-1-8108-1 Control, Directional with Sealed Switches 1 1 & Up
7-5 MZ-10007 Gauge, Battery Discharge Indicator 1 "
7-6 MZ-10028 Plate, Indicator 1 "
7-7 MX4-10206 Decal, "Vehicle Operation" 1
7-8 T6-9011-485 Decal, "Thank You" 1 "
7-9 1028 Decal, "Warning: Avoid Injury" 1 "
7-10 T-430 Decal, "Caution" 1
7-11 ¼-20 x ¾ Bolt, Hex Head Ø ¼-20 x ¾" Long 1 "
7-12 ¼ Washer, Lock ¼" ID 1 "
7-13 ¼ Washer, Flat ¼" ID 1 "
7-14 M3-1-1050 Decal, "Caution: Max. Speed" 1 "
7-15 12960001 Decal, "Fasten Safety Belt" 1 "
7-16 MX4-10052 Door, Access Console 1 "
7-17 MZ-10085 Light, LED, Green with Grommet 1 As Req'd
7-18 T-A45 Decal, "Heater" - Opt. 1 "
7-19 T-A25 Decal, Flashers 1 1 & Up
7-20 T6-7010-114 Switch, Toggle, Sealed - Heater - Opt. 1 As Req'd
7-21 T-A12 Decal, "Headlight" 1 1 & Up
7-22 T6-7010-114 Switch, Toggle, Sealed - Flashers 1 "
7-23 T6-7010-114 Switch, Toggle, Sealed - Head Light 1 "
7-24 T6-7010-114 Switch, Toggle, Sealed - Work Light - Opt. 1 As Req'd
7-25 BLE-1-2624 Switch, Toggle DPST, Sealed 1 1 & Up
7-26 BLE-1-2625 Decal, Ignition Switch 1 "
7-27
T-A38 Decal, Work Light - Opt. 1 As Req'd
7-28 660-1-2896 Flasher, Solid State 1 1 & Up
