TUG MZ - Page 159

4-2-21
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-8. Seat Assembly
Fig &
Ind
Tug Part
Number
Description Qty Effective
8-1 3/8 Washer, Flat 3/8" ID 8 1 & Up
8-2 3/8-16 x 1¼ Bolt, Hex Head Ø 3/8-16 x 1¼" Long 8 "
8-3 3/8-16 Nut, Top Lock Hex 3/8-16 8 "
8-4 3/8 Washer, Flat 3/8" ID 12 "
8-5 T6-9011-103 Belt, Seat (Retractable) 2 "
8-6 660-2-3290 Seat, Sears, Vinyl Coldform with Logo 2 "
8-7 TM1-1-9590 Bracket, Seat Belt 4 "
8-8 660-2-3290-1 Switch, Seat, Twist Lock, 2 Pin 1 "
8-9 5/16-18 Nut, Flange Lock Hex 5/16-18 8 1 & Up
8-10 MZ-10048 Closeout, Cab Harness - Opt. 1 As Req'd
8-11 BLE-ND-1075 Grommet, Rubber 7/8 x 1¼ x ¼ 1 1 & Up
