Chapter 4
MZ Tow Tractor Section 2
Table 2-9. Accelerator Pedal Assembly
Fig &
Ind
Tug Part
Number
Description Qty Effective
9-1 MZ-10016 Accelerator Assembly 1 1 & Up
9-2 5/16-24 x 1 Bolt, Hex Head Ø 5/16-24 x 1" Long 2 "
9-3 5/16 Washer, Flat 5/16" ID 2 "
9-4 5/16-24 Nut, Flange Lock Hex 5/16-24 2 "
9-5 MZ-10046 Grommet, 11/16 Rubber
1
"
9-6
HRN-MZ-80V-111
Harness, Main, MZ 80V 1 "
