TUG MZ - Page 163

4-2-25
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-10. Hydraulic System
Fig &
Ind
Tug Part
Number
Description Qty Effective
10-1 MZ-10003 Axle, Front 1 1 & Up
10-2 MT-1-1235 End, Tie Rod 2 "
10-3 ------ Fitting, Grease 2 "
10-4 5/16-18 Nut, Castellated with Pin 5/16-18 2 "
10-5 3/32 - 1½ Pin, Cotter Ø 3/32 x 1½" Long 2 "
10-6 M3-ND-5005 Fitting, Power Steering 6MJ-6MP-90L 3 "
10-7 MX4-10071 Hose, 83" (Steer Cylinder Base to Steer Valve) 2 "
10-8 MX4-10070 Hose, Power Steer, 141" (Pump to Steer Valve Pressure) 2 "
10-9 06-06-070102 Fitting, Straight 6MP x 6MJ 1 "
10-10 TM1-ND-5266 Fitting, Male Boss 45° - 6JIC Male 4 "
10-11 M3-1-8026 Pump Assembly, Power Steer, 72V OHIO 1 "
10-12 MZ-10015 Cylinder, Hydraulic Steer 1 "
10-13 660-1-3028 Valve, Steer 1 "
10-14 MZ-10080 Nut, Jam 1-16 NS 2 "
